| Processors |
1 or 2 Intel® Xeon® E5-2600/E5-2600 v2 series processors |
| Memory |
24 DDR3 RDIMMs/LRDIMMs |
| Internal Storage |
Hard disk configurations:
- 8 x 2.5-inch SAS/SATA HDDs or SSDs
- 12 x 3.5-inch SAS/SATA HDDs and 2 x 2.5-inch SAS/SATA HDDs or SSDs
- 26 x 2.5-inch SAS/SATA HDDs or SSDs
|
| RAID Support |
- RAID 0, 1, 10, 5, 50, 6, or 60
- RAID cache: 512 MB or 1 GB
|
| LOM Network Ports |
2 or 4 x GE ports, or 2 x 10 GE ports |
| PCIe Expansion |
Up to 7 PCIe 3.0 slots |
| Fan Modules |
4 hot-swappable fan modules in N+1 redundancy mode |
| PSUs |
2 hot-swappable PSUs in 1+1 redundancy mode
- 460W/800W AC PSUs
- 800W –48V DC PSUs
|
| Management |
- Provides independent ports, supports standard management interfaces, such as SNMP and IPMI, and provide the GUI, remote KVM, virtual media, SOL, intelligent power supply, remote control, and hardware monitoring
- Supports HW eSight management software and integration with third-party management systems, such as VMware vCenter, Microsoft SystemCenter, and Nagios
|
| Operating Temperature |
5ºC to 40ºC (41ºF to 104ºF) |
